Mounting; Adhesive Strip Mounting - HomeMatic IP HmIP-WRCR Montage- Und Bedienungsanleitung

Therefore, see the sticker supplied or attached to
the device.
• Wait until the connection is completed.
• If connection of the device was successful, the
LED (E) lights up green (see figure 3). The device
is now ready for use.
• If the LED lights up red, try again.
• Select the desired solution (e.g. light control) for
your device.
• Allocate the device to a room and give the device
a name.
5.2

Mounting

Read this entire section before starting to
mount the device.
You can operate the the device with
• the supplied double-sided adhesive strips or
• the supplied screws
to fix it to a wall.
You can also mount the device on a flush-mounting box.
5.2.1

Adhesive strip mounting

For mounting the device using the adhesive strips,
proceed as follows:
• Choose a site for installation.
Start-up
39
