with the back side to the wall at the position
where it should subsequently be attached (see
figure 7).
5.2.2

Screw mounting

When selecting the installation location, check
for electrical wires and power supply cables.
To install the device using screws, proceed as follows:
• Choose a site for installation.
Position the wall mounting bracket (E) on the
•
desired mounting position. Make sure that the
arrows of the mounting plate point upwards (see
figure 8).
• Use a pen to mark the positions of the two bore
holes (G) according to the mounting plate with a
distance of 67 mm on the wall (see figure 8).
• Drill the marked holes (see fig. 9).
If you are working with a stone wall, drill the
marked two 5 mm holes and insert the plugs
supplied. If you are working with a wooden wall,
you can pre-drill 1.5 mm holes to make screws
easier to insert.
• Use the supplied screws and plugs to fasten the
mounting plate to the wall (see figure 10).
• Insert of the push-button unit (A) into the wall
