Function and device overview

Using the device for any purpose other than that
described in this operating manual does not fall
within the scope of intended use and shall
invalidate any warranty or liability.
3 Function and device overview
Thanks to the button cells for power supply, the
Homematic IP Wall Switch is extra-flat and therefore
particularly flexible in use. Two intuitive push-buttons
offer comfortable control of Homematic IP devices or
system functions in the smart home. Multiple devices or
functions can be controlled simultaneously. At the push
of a button, you can for example activate the eco mode
when leaving the house and switch off the lights at the
same time.
There are virtually no limits when selecting the mounting
location thanks to battery operation and easy mounting
using adhesive strips or screws.
Device overview (see figure 1):
(A) Push-button (electronic unit)
(B)
Channel 2
(C)
System button (teach-in button and LED)
(D) Channel 1
34
