safeguarding shut-off conditions;
•
IP protection types;
•
Installation of electrical installation material;
•
Type of supply network (TN system, IT system, TT
system) and the resulting connecting conditions
(classical zero balancing, protective earthing, required
additional measures etc.).
Installation may only take place in normal
commercial switch boxes (device boxes) in
accordance with DIN 49073-1 or surface-
mounting boxes in accordance with DIN 60670-1
(e.g. Abox 025 or Abox 040). Alternatively,
installation on a mounting rail (DIN rail) in
accordance with EN 60715 is possible in
conjunction with a Wago mounting adapter
(Wago part no. 209-137).
The circuit to the which the device and the load
will be connected has to be secured by a cable
protection switch in accordance with EN60898-1
(tripping characteristic B or C, max. 16 A rated
current, min. 6 kA interrupting rating, energy limi-
ting class 3). Installation regulations according to
VDE 0100 and HD382 or 60364 have to be con-
sidered. Users must be able to easily access the
cable protection switch. This must be marked as
disconnecting device for the actuator.
Start-up
27
