Analogue Operation
When operated with a conventional transformer,
the locomotive performs like a locomotive without
a decoder. However, the locomotive will begin to
move only after a control voltage of approx. 9 V
has been reached, because the decoder requires a
certain minimum voltage simply to operate. Sound
functionality is possible during analogue ope-
ration and begins at approx. 10 V.
• In DC operation trouble-free running with
pulse-width or phase-control controllers cannot
be guaranteed.
• In AC operation the control knob is turned to
the left through the zero position as usual to
change the running direction: keep the regulator
knob pressed down for about half a second to
ensure that the reversing command has been
reliably identified! The locomotive should first
have come to a standstill in every case.
Activate or deactivation the desired sound functions
via the CV13 (only possible with a digital system).
Possible Settings in
DCC Digital Operation
The most important CV's: For the preset factory
values please see the information sheet enclosed
with the locomotive or decoder.
Notice: For the Lokmaus
responding values from 0 – 99 are programmable.
For the MULTIMAUS
the corresponding values from 0 – 255 are pro-
grammable.
CV Name
1 Adress
2 Starting voltage
(lowest creep speed)
3 Acceleration time
(from standing to maximum speed)
4 Braking time
(from maximum speed to full stop)
5 Maximum speed
6 Average speed
(by middle driving stage)
7 Decoder Version Number
read! Readable only on reading-ca-
pable amplifiers/centres)
8 Reset Function
values to the factory settings; the
manufacturer's ID is readable on
reading-capable amplifiers/centres)
, the CV's and the cor-
®
, the CV's from 1 – 256 and
®
(= short Adress)
(Returns all
value
01 – 99
01 – 252
00 – 255
00 – 255
00 – 252
00 – 252
(only
