Märklin
®
1 Trigger a reset (press "Stop" and "Go"
simultaneously for a few seconds).
2 Switch off power to rails ("Stop")
GB
3 Enter two-digit locomotive address or
"80"
4 Press travel direction selector, keep
depressed and also press "Go":
The decoder is in the programming mode
and is waiting for the register number to be
entered:
5 Enter two-digit register number (CV).
6 Press travel direction selector:
The decoder is waiting for a value to be
entered: combination of long/short tones
in quick succession.
at long intervals.
7 Enter two-digit value.
8 Press travel direction selector:
The decoder first confirms the value has
been entered with a long
followed by shor flashing at long intervals
as it waits for a new register number to be
re-entered.
9 Either reprogram the desired next register
with steps No. 5 to 8 or enter "80" for the
end of programming.
10 Press travel direction selector
Please note that the Märklin
you to enter the values 01 to 79. The value 0 does
not appear. Instead of „00" the value „80" must be
entered instead.
Programming with the Märklin
Attention! Only Märklin
in the Märklin
For docking ROCO Locomotives in the Märklin
Mobile Station, use one of the two universal num-
bers 36330/37962. They are to be set this way:
Dock the locomotive in the databank:
1. The knob must be set to 0.
2. Press the ESC button.
3. Turn the knob to the menu option ("New
Locomotive").
12
6021
short flash
Mobile Station
Mobile Station Databank.
®
at long intervals.
short double flashing
glow
6021 only allows
®
locomotives are included
®
This is
®
-
®
