Sera aqua-test Gebrauchsinformation Seite 9

lush plant growth and stable water conditions in your aquarium.
Directions for use: Shake indicator solution bottle well before using!
1. Remove the pyramid-shaped cap and fill it with the aquarium water
(approx. 1.5 ml), just below the edge.
2. Add 3 – 4 drops of indicator solution, and put the pyramid-shaped cap
back on.
3. Invert the testing device and mount it vertically to the aquarium glass
using the provided suction cup. Follow this procedure carefully, other-
wise it will lead to inaccurate results and eventually cause damage to the
testing device!
Please note: Ensure the hollow space under the device is only partly filled
with water.
4. Attach the color decal to the outside glass of the aquarium. Close to the
testing device, to compare the ongoing test colors.
5. After a prolonged period, the color in the testing device will fade. When
this happens, refill the indicator solution and aquarium water, as
described above 1 to 3. Clean the testing device.
6. If you have difficulty removing the cap of the testing device, it means the
silicon grease on the O-ring has dried up. In this case, carefully remove
the cap with a small screwdriver and grease the O-ring with silicone.
Color Evaluation, effects, corrective measures
blue insufficient CO
dosage. Follow the directions for use on the CO
tion system
dark green correct CO level
2
light green too much CO . The fish are breathing heavily near the water
2
surface or swimming abnormally. Lower the CO
Aerate the water to expel CO
Important: The sera CO long-term indicator reacts with changes of CO
2
aquarium water. Reaction time may have a delay of 30 to 60 minutes. If the
water level in the testing device changes rapidly, it means the cap is not
tightly fitted or the O-ring has become brittle and must be replaced. Please
check and correct.
magnesium-Test (saltwater)
Mg
Reagent 1 contains sodium hydroxide. Causes severe
burns. In case of contact with eyes, rinse immediately
with plenty of water and seek medical advice. In case of
accident or if you feel unwell, seek medical advice
immediately (show the label where possible). Keep
C Corrosive
locked up and out of reach of children. Wear suitable
protective clothing, gloves and eye/face protection.
An optimal magnesium level is required in a saltwater aquarium in order for
invertebrates and ornamental algae to thrive. Calcareous red algae are a per-
fect example. These ornamental algae require particularly much magne-
sium, as they integrate this element into their skeleton. Natural saltwater
contains about 1,300 mg/l. This level should also be maintained in an optimal
saltwater aquarium. The sera magnesium-Test allows you to monitor the
magnesium level in your aquarium quickly and easily. It is even easier if you
have gathered testing experience by using the sera calcium-Test. You can
easily increase the magnesium level in your saltwater aquarium by adding
sera magnesium plus.
Directions for use: Shake reagent bottles well before using!
1. Rinse the measurement vial several times with the water to be tested,
then empty the vial. Dry the vial on the outside.
2. Rinse the syringe several times with the water to be tested, then fill 2 ml
of it into the vial, using the syringe.
3. Add 6 drops reagent 1 and shake the vial until the liquid is evenly distrib-
uted. Possibly occurring cloudiness does not affect the test.
4. Add one level measurement spoon (white) reagent 2 into the vial and
gently whirl the vial (do not shake) until the powder has dissolved.
5. Add reagent 3 drop by drop while counting the drops, release the
reagent bottle from finger pressure after every 5 drops, allowing air to
be drawn into the bottle. Shake vial after every drop until the color turns
from pink into blue (not violet) and remains stable for at least 30 seconds
whilst whirling the vial occasionally. Write down the number of drops
used.
6. Empty the measurement vial, rinse it carefully with tap water and then
several times with the water to be tested, then empty the vial. Dry the
vial on the outside.
7. Take up 2 ml of the water to be tested into the syringe and fill it into the
vial.
8. Add 6 drops reagent 4 and shake the vial until the liquid is evenly distrib-
uted. Possibly occurring cloudiness does not affect the test.
9. Add one level measurement spoon (white) reagent 5 into the vial and
gently whirl the vial (do not shake) until the powder has dissolved.
10. Add reagent 3 drop by drop while counting the drops, release the
reagent bottle from finger pressure after every 5 drops, allowing air to
. Plants will not grow properly. Increase CO
2
from the water
2
be drawn into the bottle. Shake vial after every drop until the color turns
from red into green and remains stable for at least 30 seconds whilst
whirling the vial occasionally. Attention – you will need considerably
more drops for this measurement than for the first measurement!
11. Subtract the number of drops required for the first measurement from
the result of the second measurement. Multiply the remaining number
of drops by 60 to get the magnesium level in mg/l. Example: The first
measurement required 4 drops, the second measurement 24 drops. If
you subtract the first measurement result from the second one, 20 drops
will remain. 20 drops multiplied by 60 makes 1,200 mg/l magnesium.
12. Cleaning: Clean vial and syringe thoroughly with tap water before and
after each test.
O
2
C Corrosive
Oxygen is essential for all living creatures in freshwater aquariums and in
2
fertiliza-
garden ponds. Even plant life requires oxygen during the night. The oxygen
2
level depends on various factors, such as water temperature, water agita-
tion, fish and plant species and numbers, and the food amount. Lack of oxy-
gen may cause severe shortness of breath or, in severe cases, suffocation of
fish and other animals. Dangerous situations can be quickly recognized with
dosage.
the sera oxygen-Test kit. They can be remedied with sera O
2
Directions for use: Shake reagent bottles well before using!
1. Rinse the measurement vial several times with the water to be tested,
then fill to the edge. Dry the vial on the outside.
in
2
2. Add 6 drops of reagent 1.
3. Next add 6 drops of reagent 2, place the cover on the vial immediately
(ensure there are no air bubbles in the water) and then shake. Remove
the cover.
4. Compare the color of the precipitate (flakes) to the color chart to deter-
mine the oxygen level. Place the vial on the color chart and compare the
colors from a position above under natural daylight. Avoid direct sun-
light.
5. Cleaning: Clean vial and cover thoroughly with tap water before and after
each test.
Oxygen levels Evaluation, corrective measures
0.5 mg/l
2.0 mg/l
4.0 mg/l
6.0 mg/l
8.0 mg/l
SiO
3
Silicate supports the growth of diatoms in fresh and saltwater aquariums.
The sera silicate-Test allows you to monitor the silicate level reliably. Silicate
levels above 1 mg/l should be bound with sera phosvec Granulat.
Directions for use: Shake reagent bottles well before using!
1. Rinse the measurement vial several times with the water to be tested,
oxygen-Test (freshwater)
Reagent 2 contains sodium hydroxide. Causes severe
burns. In case of contact with eyes, rinse immediately
with plenty of water and seek medical advice. In case of
accident or if you feel unwell, seek medical advice
immediately (show the label where possible). Keep
locked up and out of reach of children. Wear suitable
protective clothing, gloves and eye/face protection.
dangerous level, insufficient for fish, immediately add sera
O plus
2
serious deficiency. Insufficient except for robust fish, add
sera O plus
2
sufficient oxygen supply for all species of fish
good, plenty of oxygen for all species of fish
good, plenty of oxygen for all species of fish
silicate-Test (fresh and saltwater)
Reagent 1 contains 18% sulfuric acid. Reagent 2 con-
tains (2R,3R)-2,3-Dihydroxybutanedioic acid. Causes
severe burns. In case of contact with eyes, rinse imme-
diately with plenty of water and seek medical advice.
In case of accident or if you feel unwell, seek medical
C Corrosive
advice immediately (show the label where possible). If
swallowed, seek medical advice immediately and show
this container or label. Keep locked up and out of
reach of children. Wear suitable protective clothing,
gloves and eye/face protection.
Reagent 3 contains 9% sodium hydrogensulfite and
bis(4-hydroxy-N-methylanilinium)sulfate. Harmful if
Xn
Harmful
swallowed. Irritating to respiratory system. Toxic to
aquatic organisms, may cause long-term adverse
effects in the aquatic environment. Keep locked up
and out of reach of children. Avoid contact with skin.
Do not empty into drains. Wear suitable gloves. If swal-
lowed, seek medical advice immediately and show this
container or label.
N
Dangerous
to the
environment
plus.
2
9
