First Installation; Main Menu; Channel List - Megasat HD 200 C V2 Bedienungsanleitung

4. First installation

After you have connected all necessary com-
ponents and the receiver starts, the window
with the initial installation appears. Select a
menu item with the pq buttons. Then press
the OK button to make the appropriate set-
tings.
OSD language Select the menu language here.
Country Select the country in which you are located.
FTA Select whether only free-to-air channels (On)
or also encrypted channels (Off) should be searched.
Channel search Starts the automatic channel search
EXIT Cancels the installation.
Automatic search
After you have opened the program search,
enter the start and end frequency of the tape
if necessary. The subsequent search will only
search for stations in this range. If necessary,
the symbol rate values and the modulation
can also be adjusted. With the "Free only"
item you can select whether only free-to-air
(YES) or also encrypted (NO) stations are to
be searched for. Select "Start Search" to start
the search process.
08 ENGLISH

5. Main menu

The basic navigation in the menu is done with the pq buttons (up/down), or with the t u but-
tons (right/left). To enter a menu item, press the OK button. To exit an item, press the MENU or
EXIT button. Press the MENU or EXIT button again to exit the menu.
The main menu consists of 8 submenus:
ƒ Channel list
ƒ Channel search
ƒ Language
ƒ AV settings
ƒ Time display
ƒ System
ƒ Media Center
ƒ Network

5.1 Channel list

TV channel list
In this menu item you can move, skip, lock,
delete, rename or assign channels to favou-
rite groups.
Favorites (FAV)
Select a channel and then press the FAV
button to assign the channel to one or more
Favourites lists. Several favourite groups are
available (movie, news, sports, music, ...). For
example, select "Movie" to assign the chan-
nel to the favourite group. The favourite
group is then marked with a star symbol.
Press EXIT to return to the channel list. Repe-
at the procedure with all other channels that
you want to assign to favourite lists. In normal TV mode, press the FAV key to call up the favourite
lists. Use the pq buttons to switch between the different favourite lists. Under each category, the
channels that you have marked as favorites will appear.
For example, to delete a channel from the favourite lists, change "Movies" in the favourite selection
and press OK to deactivate the channels you want to remove.
Note:
The menu is partly password protected. The
factory password is: 0 0 0 0
ENGLISH 09
