ENGINE
Model INTEK
Displacement 500 cc (30,5 cu in.)
Electrical System Alternator: 9 amp Regulated
Battery: 12V-195 CCA
Oil Capacity 1,4 L (48 oz)
Engine Oil Synthetic 5W30
Spark Plug Gap 0.030 in. (0,76 mm)
Spark Plug Torque 180 in-lbs (20 Nm)
Fuel Tank Capacity 3.5 gal (13,2 L)
CHASSIS
Seat Adjustment 9-Position
Front Wheels Tire Size: 15 x 6.0-6
Inflation Pressure: 12-14 psi (0,82 -0,96 bar)
Rear Wheels Tire Size: 20 x 8.0-8
Inflation Pressure: 10 psi (0,68 bar)
Power Ratings
The gross power rating for individual gasoline engine models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 Small Engine Power & Torque Rating Procedure, and is rated in accordance with SAE J1995.
Torque values are derived at 2600 RPM for those engines with "rpm" called out on the label and 3060 RPM for all others;
horsepower values are derived at 3600 RPM. The gross power curves can be viewed at www.BRIGGSandSTRATTON.
COM. Net power values are taken with exhaust and air cleaner installed whereas gross power values are collected without
these attachments. Actual gross engine power will be higher than net engine power and is affected by, among other things,
ambient operating conditions and engine-to-engine variability. Given the wide array of products on which engines are
placed, the gasoline engine may not develop the rated gross power when used in a given piece of power equipment. This
difference is due to a variety of factors including, but not limited to, the variety of engine components (air cleaner, exhaust,
charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature, humidity,
altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute
an engine of higher rated power for this engine.
Parts and Accessories
See an authorized dealer.
en
4175 Series
TM TM
TRANSMISSION
Make
Type
MOWER DECK
Cutting Width
Base Deck Platform
Number of Blades/Type
Frame Suspension
Deck Support Wheels/Number Standard, 4 Anti-Scalp Wheels
Height-of-Cut
Mower Lift
Cutting Positions

Specifications

Hydro Gear®
T2HP
107 cm (42 in.)
Side Discharge
2, Standard Lift
Frame Hung
1.5 to 4.0 in. (3,8 to 10,2 cm)
Manual
6
