Very Important - Thrustmaster T-LCM Redals Load Cell & Magnetics Benutzerhandbuch

CALIBRATION SOFTWARE

VERY IMPORTANT

This procedure must be followed when changing the brake pedal's resistance.
Connect the pedal set to a PC using the removable USB cable (1).
The removable RJ12 cable (2) must not be connected to the pedal set during this procedure.
Visit https://support.thrustmaster.com. Click Racing Wheels / T-LCM Pedals, then select
Software.
Download and install the calibration software:
- To adjust the dead zones at the beginning of the range of travel on all three pedals to your liking.
- To adjust the dead zones at the end of the range of travel on the accelerator pedal and clutch
pedal to your liking.
- To adjust the electronic force (Brake Force) on the brake pedal to your liking.
Once the different settings have been properly configured, click APPLY, and then disconnect
the removable USB cable (1). The settings are saved in the pedal set's internal memory:
they will be effective in all of your games, on PC and game consoles.
UPDATING THE PEDAL SET'S FIRMWARE
In order to update the firmware, the pedal set must be connected to a PC via the removable USB cable (1).
The firmware included in the pedal set can be updated with more recent versions allowing for product
improvements.
The firmware version is displayed in the lower left-hand corner of the calibration software.
To update the pedal set's firmware: on PC, visit https://support.thrustmaster.com, click Racing
Wheels / T-LCM Pedals, then select Firmware and follow the download and installation instructions
and procedure.
4/16
