4
S
pecifications
Type number A25CN-9001
CE Conformity According to low voltage directive and EMC directive
Electrical rating ~15(8) A 230 V
Max. element temperature 150 °C
Max. case temperature 55 °C
Power element Rod and tube construction
High limit dial stop Adjustable (in steps) between 50 °C and 95 °C.
Shipping weight Individual pack 0.9 kg
Enclosure (protection
Dimensions (see dimension drawing)
The performance specifications are nominal and conform to acceptable industry standards. For applications at conditions beyond
these specifications, consult the local Johnson Controls office or representative. Johnson Controls shall not be liable for damages
resulting from misapplication or misuse of its products.
Johnson Controls International, Inc.
Headquarters:
Milwaukee, WI, USA
European Headquarters:
Westendhof 8, 45143 Essen, Germany
European Factories:
Lomagna (Italy), Leeuwarden (The Netherlands) and Essen (Germany)
Branch Offices:
Principal European Cities.
This document is subject to change
Catalogue Section 1
Range 0 to 100 °C
Reset Positive, trip-free reset mechanism. Control can be reset when
temperature drops 15 K below dial setting.
Overpack 15 kg (16 pcs)
IP30
class)
A25
Issue 25/04/2003
Printed in Europe
© 2003 Johnson Controls Inc.
Order No. PD-A25-E
