Maxwell Digital Multimeters 25331 Gebrauchsanweisung Seite 4

A~
Range
200 mA
10 A
Max. inward current
Fuse
Frequency range
Resistance
Range
200 Ω
2 kΩ
20 kΩ
200 kΩ
2 MΩ
20 MΩ
Overvoltage protection: 250 V (DC/AC RMS)
Warning: Do NOT measure voltage in resistance mode!
Diode and continuity test
Function
opening voltage of
Overvoltage protection: 250 V (DC/AC RMS)
Accuracy
±1%
±1.5%
10 A (testing time should be 10 sec max.)
0,5 A/250 V and 10 A / 250 V fast fuse
40 Hz - 400 Hz
Accuracy
±1.5%
Description
Measures the
the diode
Beeping sound
if the resistance
is lower than
(30±20)Ω
Resolution
100 μA
10 mA
Resolution
0.1 Ω
1 Ω
10 Ω
100 Ω
1 kΩ
10 kΩ
Test state
The opening DC amperage is
approx. 1 mA, the closing voltage is
approx. 2,7 V
Open circuit voltage: 1.5V
