˜ Removing segments (Fig. D)
Note: The segments which can be removed are marked with an
arrow (see Fig . D) . They are connected together with pins . These can
be pushed out in the direction of the arrow with the repair set
a pair of tweezers if necessary in order to remove the pins .
Place the watch with the dial facing downwards in the repair
set .
8
Remove the pins of the segment that you wish to remove (as
described above) and take out the segment
Note: If you would like to take out more than one consecutive
segment
7
Connect the watch strap together again by joining the loose
segments
7
arrow into the adjacent segments
, it is sufficient to remove the two outer pins .
with a pin . Press this pin against the direction of the
.
7
.
7
. Use
8
GB/IE/NI 11
