Change the Print and Retransfer Ribbons

Change the Retransfer Ribbon

Before you change or first install the Everest retransfer ribbon, allow time for
the new ribbon to become acclimated to the environment. Allow more time
for greater temperature and humidity differences.
Important!
Rimage supports only the use of Rimage brand ribbons in our printers.
•
Printer issues that occur as a result of using ribbons by manufacturers
other than Rimage are not included under your Rimage warranty or
maintenance agreement.
For optimum results, make sure that Everest ribbons are stored at a
•
temperature between 41° and 95°F (5° to 35°C) and humidity level
between 45% and 85%.
Avoid moisture and direct sunlight.
•
Do not reuse ribbons.
•
Make sure you only use ribbons designed for your model of Everest 400
•
printer.
The ribbon carriers cannot be removed from the printer unless the
•
system is powered on.

Remove the Retransfer Ribbon

1. Open the printer cover.
a. Lift the cover latch to release the cover.
b. Lower the printer cover.
Printer Cover
2001431_C
All manuals and user guides at all-guides.com
Printer Cover
Latch
Left Side of Autoloader
For more information visit
c. Turn the center latch counterclockwise to unlock it.
d. Pull the retransfer ribbon carrier all the way out of the printer.
Important! The ribbon carriers cannot be removed from the printer
unless the system is powered on.
e. Lay the retransfer ribbon carrier on a flat surface.
Center
Latch
2. Remove the used retransfer ribbon.
a. Lift up on the take-up roll to remove it from the right side of the
carrier.
b. Set the take-up roll aside.
rimage.com/support
Retransfer
Ribbon Carrier
Used Take-Up Roll
19
