To delete the video that is marked in the video list, press the talk
button [12]. When the symbol appears, confirm by pressing
the menu button [9]. (If you don't want to delete the video,
press the button [10].)
!
To delete all videos in the monitor, press the door release button
[11] in the video list and confirm by pressing the menu
button .
Notes:
#
A microSDHC card is required to record videos.
#
A maximum of 1000 videos can be stored. The maximum lenght of
a video is 75 seconds.
#
The name of the video is the recording date and time
(e.g. 01162020111028 = 01/16/2020 at 11:10:28)
DEFAULT SET. - reset
Notes:
#
Resetting deletes all of the snapshots.
#
Following a reset, the outdoor station is no longer paired with the
monitor.
#
The date and time are not affected by the reset.
!
To restore the factory settings, select "YES".
!
Then confirm by pressing the menu button [9].
14. Function of an optional signal
generator / optional door release
button
14.1 Optional signal generator
When the doorbell button [25] on the outdoor station to which the
signal generator is attached is pressed, the signal generator is
activated for approx. 3 seconds.
The outdoor station DVT60T2 has only one wired output for a signal
generator. This output is assigned to the upper doorbell button, i.e. the
family who needs the signal generator has to choose the upper doorbell
button.
14.2 Optional door release button
When the door release button is pressed, the door release that is
connected to the same outdoor station as the door release button is
activated for the time set on the monitor.
15. Tamper alarm
If a paired outdoor station that is connected to the power supply or
which has batteries fitted is removed from the protective cover, a
pulsating tamper alarm sounds on the outdoor station and the monitor
for approx. 5 minutes.
!
To switch off the tamper alarm, press the on/off button
the talk button [12] on a monitor.
38 - GB
16. Wireless range
The wireless range is dependent on many factors. In an ideal location
and by free line of sight between both antennas, a range of approx.
100 -150 m is possible, within buildings this is reduced to maybe
20 m. The range cannot be guaranteed as it is dependent on the local
conditions.
In order to avoid malfunctions, only one wireless system should be fitted
for each monitoring location/building/home.
A reduction of the range will be caused by:
#
Walls and Floors, in particular those of metal or with metal
reinforcement
#
Metal surfaces e.g. refrigerator, metal shelves
#
Coated windows (eg. those with Insulating glass), radiators, mirrors
#
Strong electric fields and other radio equipment, eg. microwave
ovens, radio telephones, mobile phones, radio equipment in the 2.4
GHz range, electric motors and power cables
#
Devices using the same or similar frequency (eg. WLAN-systems)
#
Weather conditions (rain, fog etc.)
#
Major obstacles outdoors
17. Changing the batteries at the
outdoor station
If no sound can be heard after pressing the door bell button [25] or if a
flashing red battery symbol
screen and there is only one bar in the battery status indicator [2], then
the batteries must be changed.
In this case:
!
First release the torx screw [33] with the torx screwdriver [41]
provided and remove it.
!
Lever the outdoor station [20] out of the protective cover [32]. If a
tamper alarm sounds despite the battery charge being low, switch
it off on the monitor by pressing the
!
Unscrew the battery compartment [30] cover screw and remove
the cover.
!
Remove the expired batteries and place 2 new LR14 (C), 1,5 V
alkaline batteries in the battery compartment observing the
correct polarity.
!
Re-attach the battery compartment cover to the outdoor station
with the screw.
!
Push the outdoor station back into the protective cover and screw
it into position again with the torx screw.

18. Maintenance and cleaning

#
The products are maintenance-free: Never open them, except
when changing batteries.
#
Check the safety and function regularly.
[13] or
#
Remove the mains adapters from the mains sockets or disconnect
from the power supply before cleaning.
#
Use a soft, slightly moist cloth or brush to clean the surfaces.
( ! ) appears in the middle of the
[13] or [12] button.
