If you wish the monitor to be portable, insert the optional AKKU-
DVT67M lithium battery into the battery compartment [3], paying
attention to the correct polarity.
!
If the battery is inserted, the battery charge display
right of the start screen [2] indicates the charge status of the
monitor. During mains operation, the battery charge display
shows loading (even if no battery is inserted).
!
To switch the monitor off, press and hold the on/off button
[13] on the monitor with the screen on for approx. 5 seconds,
until the display on the screen disappears.
Note:
When the monitor is switched off:
#
it does not respond to a ring on the door intercom and
#
no camera image is saved
#
but if an optional signal generator is connected, it will still
respond to a ring
#
approx. 6 seconds after a ring, a double tone on the outdoor
station can be heard as a signal that there is no mobile unit to
respond when no additional monitor is connected or the
additional monitor is also switched off.
11. Basic functions
a monitor and a connected door release)
11.1 There is a ring on the outdoor station
!
Ringing:
Pressing the doorbell button [25] results in
#
a quiet "plop" sound on the outdoor station,
#
a bell rings on the monitor and the outdoor station (
tone, duration and volume can be set or switched
off )
#
"Call In" appears briefly on the screen [2] of the monitor and
the camera image from the outdoor station appears. If the
conversation is not accepted, the camera image switches off
after approx. 30 seconds (or after the set duration).
#
As soon as the
camera image from the door intercom is saved on the monitor
(provided that the snapshot function in the menu is activated).
#
The light [24] on the ring button on the outdoor station
flashes. If the conversation is not accepted, the flashing light
goes off after approx. 30 seconds (or after the set duration)
and there is a quiet "plop" sound on the outdoor station.
!
Speaking:
By pressing the talk button
conversation and activate the talk function as long as the camera
picture is visible on the screen:
#
Activation is indicated by the
#
As long as the talk function is active, the camera image from
the outdoor station is displayed and the light [24] on the ring
button flashes.
34 - GB
(with an outdoor station,
symbol is displayed, a snapshot of the
[12] you can accept the
symbol.
#
Now either the sound from the microphone [21] on the
outdoor station can be heard over the loudspeaker [7] on the
monitor or the sound from the microphone [15] on the
at the top monitor can be heard over the loudspeaker [18] on the
outdoor station in alternation (intercom function).
#
Press the
camera and save it on the monitor; the
briefly.
#
The talk function can be ended by pressing the on/off button
seconds, the start screen appears again and the screen goes
off after approx. 20 seconds. Ending the talk function is
indicated by a quiet "plop" sound on the outdoor station.
!
Opening the door:
If an electric door release is connected to the outdoor station, it can
be activated by pressing the door release button
soon as the camera image from the outdoor station can be seen on
the monitor. Opening the door stops the ringing process and the
talk function, a quiet "plop" sound can be heard on the outdoor
station, the start screen reappears on the monitor and the screen
switches off after approx. 20 seconds.
Notes:
#
In poor light conditions, the white LEDs [22] are activated as soon
as the doorbell button is pressed or the camera image is switched
on manually with the
0.8 m in front of the outdoor station is illuminated by this.
Additional lighting must be fitted to achieve a better image in the
dark.
ring
#
If:
then:
If the system is still not working as expected, even when the
devices are next to one another, they must be paired again (see
section 13.2 "Register").
#
The strength of the incoming wireless signal is displayed by the
symbol
[2]. The bars next to the antenna symbol indicate the strength.
#
A symbol on the top left of the camera image on the screen
indicates whether the door intercom showing the camera image is
being supplied with power by the power supply unit (
batteries (
#
If there is a ring on the intercom and a snapshot is saved but the
conversation is not accepted on a monitor, a new snapshot is
indicated by the flashing red
button [10] to take another static image on the
[13]; otherwise, it ends automatically after approx. 45
button. The immediate area up to max.
B
the monitor does not respond when the bell
button is pressed but the ring tone can be heard on
the outdoor station
B
or no camera image is visible on the monitor
when operating with the power supply unit,
B
switch the monitor on by pressing and holding the
on/off button [13] for approx. 5 seconds
B
or reduce the distance between the monitor and
the outdoor station.
on the top right of the camera image on the screen
) .
symbol at the top left of the
symbol appears
[11] as
) or by
