Motherboard Layout (AD2700-ITX)
1
USB 2.0
T: USB0
B: USB1
1
USB 3.0
T: USB2
B: USB3
20
USB 2.0
Top:
T: USB4
RJ-45
B: USB5
AUDIO
CODEC
19
1
Print Port Header (LPT1, White)
2
COM Port Header (COM1)
3
CPU Fan Connector (CPU_FAN1)
4
CPU Heatsink
5
Chassis Fan Connector (CHA_FAN1)
6
2 x 240-pin DDR3 SO-DIMM Slots
(DDR3_A1, DDR3_A2, Black)
7
ATX Power Connector (ATXPWR1)
8
SATA2 Connector (SATAII_2, Blue)
9
USB 2.0 Header (USB8_9, Blue)
10
Infrared Module Header (IR1)
11
System Panel Header (PANEL1, White)
2
ASRock AD2700-ITX / AD2500-ITX Motherboard
3
2
17.0cm (6.7 in)
ErP/EuP Ready
COM1
1
CPU_FAN1
Super
IO
LPT1
RoHS
LAN
PHY
CMOS
Battery
16Mb
BIOS
AD2700-ITX
HD_AUDIO1
PCI1
USB 3.0
18
12
13
14
15
16
17
18
19
20
4
5
CHA_FAN1
SATAII_1
SATAII_2
1
USB8_9
IR1
1
1
USB6_7
PLED PWRBTN
1
CIR1
1
HDLED RESET
PANEL 1
CLRCMOS1
SPEAKER1
1
1
Design in Taipei
17
16
15
14
13
Consumer Infrared Module Header (CIR1)
Clear CMOS Jumper (CLRCMOS1)
Chassis Speaker Header
(SPEAKER 1, White)
USB 2.0 Header (USB6_7, Blue)
SATA2 Connector (SATAII_1, Blue)
16Mb SPI Flash
PCI Slot (PCI1)
Front Panel Audio Header
(HD_AUDIO1, White)
Intel NM10 Express Chip
6
7
8
9
10
11
12
