4. OPERATION / VENTILATION
( not valid for mirrors and stainless steel front )
The functions of the CARTA-Glas hood are controlled via a touch control panel.
( mirror and stainless steel versions via switch (Pos.11) and IR remote control ) .
The control unit has 3 fan power levels and one intensive level, as well as a lighting
funtion.
A
Selecting
Fan stages 1-2-3-Int. are ready for operation.
Device ON = Symbol backlit, press again Device OFF
B
Fan power levels 1-2-3 by pressing the respective power level, it becomes active
1 2 3
and starts somewhat delayed. Press power level again.
The active power level is backlit.
C
Intensive level
Press the Int symbol to activate the intensive stage (max. fan output).
Int.
The motor automatically switches back to the previously active stage after
approx. 3 minutes.
The active power stage is backlit.
D
Lighting
Press the lighting symbol to switch on the lighting.
Press the light symbol again Light goes out.
E
Grease filter cleaning
If the grease filter indicator ( E ) flashes, the condensation filter must be cleaned.
After cleaning the filter, reinsert the filter and reset the grease filter display. Press
and hold symbol "A" for at least 3 seconds, symbol "1" no longer flashes. To
reset the grease filter display, the hood must be in "ON" mode. The grease filter
display is activated after max. 40 operating hours.
28

OPERATING INSTRUCTIONS

the ON / OFF symbol switches the device ON.
