The design, manufacturing and requirements for the intended use of the product are based on the
expected service life. These also include the requirements for maintenance, ensuring effective­
ness and the safety of the product.
Using the product beyond the specified expected service life leads to increased residual risk and
should only take place subject to the due diligence and deliberations of qualified personnel.
If the service life is reached, the user or a responsible attendant should contact the qualified per­
sonnel who fitted the product or the manufacturer's service (see inside or outside of rear cover for
address). Here the user can obtain information about known risks and the current options for
refurbishing the product.

11 Technical data

Dimensions, weights, temperatures
Dimensions (depth x width)
1)
Weight [kg (lbs)]
User weight [kg (lbs)]
Temperatures [°C (°F)]
Functional heights
Ischial zone [mm (")]
Support for trochanters [mm (")]
Thigh trough [mm (")]
Edge area [mm (")]
Component
Foam base
Foam density (ISO 845) [kg/m
Foam firmness (ISO 3386) [kPa]
®
LiquiCell packs (in 476C00=SK65/8/9*)
Cover
1)
Reference size 405 x 405 mm (16" x 16"), in ready-to-use condition, without incontinence cover

1 Avant-propos

INFORMATION
Date de la dernière mise à jour : 2019-02-13
Veuillez lire attentivement l'intégralité de ce document avant d'utiliser le produit.
►
► Respectez les consignes de sécurité afin d'éviter toute blessure et endommagement du pro­
duit.
► Apprenez à l'utilisateur à bien utiliser son produit et informez-le des consignes de sécurité.
► Conservez ce document.
INFORMATION
► Vous trouverez de nouvelles informations sur la sécurité et les rappels du produit auprès du
Customer Care Center (CCC) à oa@ottobock.com ou auprès du service après-vente du fa­
bricant (voir adresses en 3ème ou 4ème de couverture).
20
1)
3 3
(lbs/ft )]
see label on the cover
Terra (476C00=SK60/3/4*): 1 (2.2)
Terra Aquos (476C00=SK65/8/9*): 1.2 (2.6)
35 (77)–150 (330)
0 (+32)–+40 (+104)
70 (2.7) (see fig. 3, item 3)
75 (2.9)
60 (2.3) (see fig. 3, item 4)
95 (3.7) (see fig. 3, item 2)
Material
Rest suspension PU foam
100 (6.24)
11
Silicone oil, PU film
PU-coated fabric, washable
