LIST OF PARTS - DIAGRAM – P. 33
No. description
1 Main frame
2 Handlebar
3 Handlebar column
Rear stabilizer Φ50×1.5
4
Drive wheel Φ180×25
5
Front stabilizer Φ50×1.5
6
7 Resistance control knob
8 Saddle adjustment knob M16
9 Drive belt 290/J4
10 Counter
11 Support
12 Plastic bushing
13 Left cover
Spring 65Mn/Φ10×50vδ1.0
14
Tap screw ST2.9×9.5
15
Flat washer Φ23×Φ35×2.0
16
17 Bushing (7/8)"
18 Bolt
19 Belt pulley 6"
20 Left step (1/2)"
21 Right step (1/2)"
PREPARATIONS
1. Before assembly make sure there is enough space.
2. Use the recommended tools.
3. Before assembly check if there are all the parts in the box.
It is recommended that product should be assembled by at least two people
to avoid injuries.
ASSEMBLY INSTRUCTIONS (Drawings – p. 34-36)
Note: Follow the assembly instructions below:
STEP 1 Assembly of the front and rear stabilisers
Attach the front stabilizer (6) at the front part of the main frame (1) using
two bolts (35), two curved washers (36) and two nuts (34). Tighten the nuts
using multifunction key.
Then, attach the rear stabilizer to the main frame (1) using two bolts (35),
two curved washers (36) and two nuts (34). Tighten the nuts using
multifunction key.
STEP 2 Assembly of steps
Knobs and other components are marked with "R" (right) and "L" (left)
letters to make their identification easy.
Pass the left step axle (20) through the threaded hole in the left step crank.
Then tighten the step axle counter clockwise to attach the step in place.
ATTENTION: turning the step axis clockwise may result in twisting and
tearing of the thread.
Tighten the step axle using multifunction key with the Phillips screwdriver,
included in the set.
Pass the right step axle (21) through the threaded hole in the right step
crank. Then tighten the step axle counter clockwise to attach the step in
place.
Tighten the step axle using multifunction key with the Phillips screwdriver,
included in the set.
STEP 3 Assembly of the handlebar column
Using the Allen wrench S6, remove four hexagonal screws M8x15 (24) with
four convex washers (37) from the main frame (1). Connect the two
terminals of the sensor cable (26) and (59). Then, connect the two terminals
ASSEMBLY, SETUP AND MAINTENANCE
pcs. No. description
Bearing bushing Φ55.6×16
1 22
Bearing Φ44.5
1 23
Bolt M8×15
1 24
1 25 Saddle column
1 26 sensor cable L=350mm
1 27 Saddle
1 28 Front stabiliser plug
1 29 Rear stabiliser plug
Flywheel axle Φ17×90
1 30
1 31 Bearing
Convex washer Φ17
1 32
1 33 Nylon nut M6
1 34 Nut M10
Bolt M10×56
1 35
Curved washer Φ10×Φ20×1.5
2 36
Convex washer Φ8
1 37
Flat washer Φ8
1 38
Bolt M8×20
1 39
Tap screw ST4.2×25
1 40
Spring Φ20×39×δ3.2
1 41
1 42 Nylon nut M8
6
pcs. No.
2
2
6
1
1
1
2
2
1
2
1
1
4
4
4
6
5
1
7
1
4
Most of the assembly equipment listed here has been packed separately,
but some elements come preassembled in certain assembly parts. If it is
required, dissassemble them and assemble again.
Read the instructions of all assembly steps and familiarize with all the
devices installed.
of resistance adjustment cable (7) and (54), placing the end of the
resistance adjustment cable (7) in the metal opening of the cable hook (54).
The method of connecting both cables is shown in the figure.
Place the handlebar column (3) on the handlebar column base (1) and
attach it with four hexagonal screws M8x15 (24) and four convex washers
(37), using the Allen wrench S6.
STEP 4 Assembly of the saddle column
Using the multifunction key with Phillips screwdriver, remove the three flat
washers (38) with the three nylon nuts M8 (42) from the saddle bar base
(27). Pass the bolts being at the lower side of the saddle through the
openings in the upper part of the saddle column (25) and attach using the
three, earlier removed flat washers (38) and three nylon nuts (42). Screw
them in using the multifunction key with the Phillips screwdriver.
Place the saddle column (25) on the plastic sleeve in the saddle column
base on the main frame (1) and attach the saddle column adjustment knob
(8) in the opening in the saddle column base on the main frame (1)
clockwise. Tighten to fix the saddle column in selected position.
STEP 5 Assembly of the counter
Remove the two bolts M5 (63) from the counter (10). Connect the speed
sensor (59) and the heart rate sensor cables (53) to the counter. Hide all
the cables in the handlebar column. Using the multifunction key with the
Phillips screwdriver, attach the counter (10) on the handlebar column (3)
using the two earlier removed bolts M5 (63).
NOTE: before you start the training, make sure that all the bolts and nuts
are securely tightened.
The blinds of the back stabilizer are used to level the bicycle.
description
Bolt M6×20
43
44 Metal plate
45 Bearing
Curved washer Φ5
46
Bushing Ф21×Ф15.2×3.0
47
Flat washer Φ40×2.8
48
49 Saddle plug
Foam grip Φ21×Φ27×500
50
51 Bolt
Circlip Φ10
52
53 Heart rate sensor
54 Resistance regulation cable
55 Bolt M6
Flat washer Φ5
56
Bolt M5×45
57
58 Bushing (15/16)"
59 Sensor cable L=750mm
60 Plug
61 Right cover
Tap screw ST4.2×25
62
Bolt M5×10
63
pcs.
1
1
2
1
1
1
2
2
2
1
2
1
1
2
1
1
1
2
1
4
2
