Troubleshooting

Most difficulties in audio systems are the re-
sult of incorrect connections, or improper
control settings. If you encounter problems,
isolate the area of the difficulty, check the con-
trol settings, determine the cause of the fault
and make the necessary changes. If you are
unable to get sound from the RCD-1070, re-
fer to the suggestions for the following con-
ditions:
Power Indicator Is Not Lit
The Power Indicator and the basic items in
the Display window should be lit whenever
the RCD-1070 is plugged into the wall power
outlet and the Power button is pushed in. If it
does not light, test the power outlet with an-
other electrical device, such as a lamp. Be sure
the power outlet being used is not controlled
by a switch that has been turned off.
9
Fuse Replacement
If another electrical device works when plugged
into the power outlet, but the Power Indica-
tor and the Display still will not light when the
RCD-1070 is plugged into the wall outlet, it
indicates that the internal power fuse may have
blown. If you believe this has happened, con-
tact your authorized Rotel dealer to get the
fuse replaced.
No Sound
Check the cables between the RCD-1070 and
the amplifier inputs to be sure they are con-
nected properly. Be sure the amplifier input
that the RCD-1070 is selected. Be sure the tape
monitor system of the amplifier has not been
activated. Check the wiring between the
amplifer and the speakers.

Specifications

Total Harmonic Distortion + Noise
Intermodulation Distortion
Frequency Response (± 0.5 dB)
Channel Balance
Phase Linearity
Channel Separation
Signal to Noise Ratio
Dynamic Range
Digital to Analog Converters
Speed Accuracy, Wow & Flutter
Output Impedance
Digital Output
Load Impedance
Power Requirements
USA Version
European Version:
Power Consumption
Dimensions (W, H, D)
Front Panel Height (for rack mount)
Weight (net)
All specifications are accurate at the time of printing. Rotel reserves the right to make improvements without
notice.
Rotel and the Rotel HiFi logo are registered trademarks of The Rotel Co, Ltd., Tokyo, Japan.
®
, HDCD High Definition Compatible Digital
trademarks or trademarks of Pacific Microsonics, Inc, in the United States and /or other countries.
0.0045% @ 1kHz
0.0045% @ 1kHz
20-20,000 Hz
± 0.5 dB
± 0.5 degree
> 98 dB @ 1kHz
> 100dB
> 96 dB
18 bit equivalent, multi-level Delta-Sigma DAC with
8x oversampling digital filter and HDCD
Quartz Crystal Precision
100 Ohms
0.5 Volt, Peak to Peak
75 Ohms
AC 115V, 60 Hz
AC 230V, 50 Hz
20 Watts
17 x 3 11 / x 13 1 / inches
16 4
432 x 93 x 337 mm
5
3 / inches, 80 mm
32
5.8 kg, 12.8 lb.
®
and Pacific Microsonics™ are either registered
