No. Description
1
ATX 12V Power Connector (ATX12V1)
2
CPU Fan Connector (CPU_FAN1)
3
Chassis Fan Connector (CHA_FAN2)
4
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5
ATX Power Connector (ATXPWR1)
6
USB 3.0 Header (USB3_2_3)
7
SATA3 Connector (SATA_2)
8
SATA3 Connector (SATA_1)
9
SATA3 Connector (SATA_8)
10 SATA3 Connector (SATA_7)
11
Chassis Fan Connector (CHA_FAN1)
12
Chassis Speaker Header (SPEAKER1)
13
System Panel Header (PANEL1)
14
Clear CMOS Jumper (CLRCMOS1)
15
Power LED Header (PLED1)
16 SATA3 Connector (SATA_4)
17
SATA3 Connector (SATA_6)
18
SATA3 Connector (SATA_5)
19
SATA3 Connector (SATA_3)
20 USB 2.0 Header (USB8_9)
21 USB 2.0 Header (USB6_7)
22 Infrared Module Header (IR1)
23 COM Port Header (COM1)
24
SPDIF Out Connector
25 Front Panel Audio Header (HD_AUDIO1)
2
(HDMI_SPDIF1)
