Serial port Header
(9-pin COM1)
(see p.1 No. 23)
SPDIF Out Connector
(2-pin HDMI_SPDIF1)
(
see p.1 No. 24)
This COM1 header supports a
RRXD1
DDTR#1
DDSR#1
CCTS#1
1
RRI#1
RRTS#1
GND
TTXD1
DDCD#1
Please connect the
1
SPDIF_OUT connector of
GND
a HDMI VGA card to this
SPDIFOUT
header with a cable.
FM2A88X Pro+ R2.0
serial port module.
21
