Specifications

Specifications
Picture Tube
Input Signal
Display Colours
Synchronisation
Range
Resolution
Video Band Width
Active Display
Area (Factory Set-
ting)
Active Display
Area (Full Scan)
Rated Voltage
Rated Current
43 cm (17 inch) flat square CRT, 39,6 cm usable square
0.28 mm Trio dot pitch Dot type black matrix Medium-
short persistence phosphor, dark bulb, glass with anti-
static coating
Analog 0.7 Vp-p 75 Ω Positive
Video
Sync Separate sync.
Horizontal sync.
Vertical sync.
Composite sync.
Sync. on green
Analog Input: Unlimited colours (Depends on the
graphics Board)
Horizontal 31 kHz to 65 kHz (Automatically)
Vertical 55 Hz to 100 Hz (Automatically)
Horizontal 1024 dots (non interlaced)
Vertical 768 lines (non interlaced)
85 MHz
Horizontal 306 mm (Active display area is
dependent upon the signal timing)
Vertical 230 mm (Active display area is
dependent upon the signal timing)
Horizontal 316 mm (Active display area is
dependent upon the signal timing)
Vertical 237 mm (Active display area is
dependent upon the signal timing)
AC 220-240 V 50/60 Hz
1.3 A
E-25
TTL Level
Positive/Negative
Positive/Negative
TTL Level
Positive/Negative
(0.3 Vp-p) Negative
