OSM Menus
Advanced Geometry Controls Menu
The Advanced Geometry controls allow you to adjust the corners of
your display.
Top In/Out (upper corner distortion): upper bow.
Top Left/Right (upper corner distortion balance): upper bow
balance.
Bottom In/Out (lower corner distortion): lower bow.
Bottom Left/Right (lower corner distortion balance): lower bow
balance.
While in the Advanced Geometry Controls Menu, the buttons on the
front of the monitor work as follows:
exit: exits to the main menu.
control up/down: moves the highlighted area up/down to select one of
the choices.
control +/-: moves the bar in the + or - direction to increase or decrease
the adjustment.
proceed: proceeds to the controls in that sub-menu
reset: resets the current highlighted control to the factory setting.
Note: a warning window will allow you to choose to reset the
currentcontrol or to cancel reset of the current control.
Advanced Geometry
Top:
In/Out
Left/Right
Bottom:
In/Out
Left/Right
E-19
