Connection
Connection to your personal computer (NEC, IBM and
compatibles)
The MultiSync XV-series colour monitor compliments NEC or IBM
PC/XT, AT, 386, 486, PS/2 computer and compatibles.
Your System should have one of two configurations:
1. The video controller is built into the computer.
2. The video controller is in the form of a video card (sometimes
referred to as a graphic card, video adapter, or graphics
board.)
Both configurations have a video connector (or a CRT PORT
on NEC laptop computers). If you are not sure as to which
connector is the video connector, consult your computer or
video card manual.
To attach the monitor to your system, follow the instructions
below.
1. Turn off the power to the monitor and computer.
2. If necessary, install the video card. For more information,
refer to the manual accompanying the card.
3. Connect the MultiSync XV-series Monitor's video cable to
the video connector of your system.
4. Connect one end of the power cable to the MultiSync
XV-series monitor and the other end to the power outlet.
5. Turn on the monitor and computer.
6. This completes the installation
If you have any problems, please refer to the section "Trouble
Shooting".
