Connecting the monitor and turning
Connecting the monitor to a computer
(PC etc.)
When connecting, ensure that both the monitor and
computer are switched off.
Note:
- Do not overly bend the cable or add extension
cords as this could lead to malfunction.
Firmly insert the analog RGB terminal
(mini D-sub 15 pin with 3 rows) then
tighten the screws each side.
RGB signal cable
If connecting to a D-sub 15 pin 2 row Apple
Power Macintosh, attach a Macintosh conver-
sion adapter (to be purchased separately) to
the RGB signal cable.
Macintosh conversion adapter
RGB signal cable
After connecting the adapter, tighten the
screws on each side to fix into place.
the monitor on and off

Connecting the monitor to a power source

Before connecting, first turn off the monitor's main
power switch.
Note:
-
1. Connect the AC adapter to the monitor's power
2. Attach the power cord to the AC adapter and

Turning the power on

1. Press the monitor's power button.
2. Turn on the computer.
12
Do not overly bend the cable or add extension
cords as this could lead to malfunction.
terminal.
Power terminal
place the power plug into the AC terminal.
The power LED will be lit green, and the screen
will display an image.
Press power button
AC adapter
AC terminal
Power cord
Turn on device to
which monitor is
connected
ON
