Adjusting the screen display

Adjustment the backlight (right column)
Brightness of backlight can be adjusted.
Automatic screen adjustment (p.18)
The CLOCK, PHASE, H-POS (horizontal position-
ing) and V-POS (vertical positioning) functions can
be adjusted automatically.
Manual screen adjustment (p. 19)
Fine adjustments can be made using the On Screen
Display (OSD) Menu.
Note:
- All adjustments will be saved even after turning
the power off.
Resetting all adjustment values
All adjustment values can be returned to their
original ex-factory values in one command.
1. Turn off the monitor power.
2. Press the MENU button and the SELECT button
simultaneously, and while doing this press the
power button (i.e. turn the power on). When [ALL
RESET] appears on the screen, the reset is
complete.
3. Turn off the monitor power.
Note:
- While ALL RESET is displayed, the control
buttons are disabled.
- It is not possible to reset values when the
adjustment lock is in place. Remove the
adjustment lock before attempting to operate
control buttons.
ADJUSTMENT menu reset
The adjustment values of the analogue signal time's
ADJUSTMENT menu can be returned to their
original ex-factory values.
1. Turn on the monitor power.
2. Press the MENU button and the
simultaneously. When [RESET] appears on the
screen, the reset is complete.
Adjustment lock function
By disabling the control buttons (i.e. setting the lock)
any attempted changes to adjusted values will be
voided.
1. Turn off the monitor power.
2. While pressing the MENU button, press the
power button (i.e. turn the power on).
Continue to press the button until the message
appears on the screen.
When the menu is unlocked:
[ADJUSTMENT LOCKED] will appear on
the screen, and the lock will be set.
When the menu is locked:
[ADJUSTMENT UNLOCKED] will appear
on the screen, and the lock will be
removed.
Note:
- When the lock is in place, all buttons other than
the power button are disabled.

Adjusting the backlight

1. Without the OSD Menu being displayed, press
the
B R I G H T
2. Adjust by pressing the
button (lighter).
The BRIGHT bar automatically disappears
several seconds after the last command.
button
17
button or the button.
3 1
button (darker) or the
