MAINTENANCE

5.10. Replacing the Gloves

1
Gloves
Fig 4
1 Cuff tube (protective rubber) for outer glove
2 Outer glove
3 Inner glove
4 Tube piece
Disassembling the outer gloves
(1) Pull off cuff tube.
(2) Pull off outer glove.
Disassembling the inner gloves
(1) Open zip fully.
(2) Turn the sleeves of the protective suit inside out.
(3) Loosen screw and nut clamp (SW7).
(4) Pull out tube piece with glove.
(5) Pull glove off tube piece.
18
4
3
2
Vautex Elite S
7
6
5
5 Rubber ring
6 Clamp protection
7 Screw and nut clamp
