1. Description

1.1 Application

The SKF Multi-Point Lubricator LAGD 1000 can supply up to 20 lubrication points
(depending on variant) with a metered amount of lubricant (0,2 cm
can be power by AC or DC. The LAGD 1000 has a large 1 litre grease
reservoir that is supplied to a micro processor controlled pump unit. The pump is
programmed to operate for one or more cycles with a pause time in between. Each cycle
of the pump supplies grease to a progressive distributor that supplies a metered amount
of grease to the application, via pipes.

1.2 Identification of parts

Fig 1 Scope of delivery of the LAGD 1000
8
). The LAGD 1000
3
1
2
4
5
8
6
7
3
