Motherboard Layout
USB 2.0
T: USB0
B: USB1
USB 3.0
T: USB0
B: USB1
USB 2.0
T: USB2
B: USB3
46
45
44
43
42
41
40
39
38
AUDIO
CODEC
37
36
HD_AUDIO1
35
1
ATX 12V Power Connector (ATX12V1)
2
Power Fan Connector (PWR_FAN1)
3
1155-Pin CPU Socket
4
CPU Fan Connector (CPU_FAN1)
5
CPU Fan Connector (CPU_FAN2)
6
2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A1, DDR3_B1, Black)
7
2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A2, DDR3_B2, Black)
8
ATX Power Connector (ATXPWR1)
9
Chassis Fan Connector (CHA_FAN1)
10
Clear CMOS Jumper (CLRCMOS1)
11
SATA3 Connector (SATA3_M1, Gray)
12
SATA3 Connector (SATA3_M2, Gray)
13
SATA3 Connector (SATA3_0, Gray)
14
SATA3 Connector (SATA3_1, Gray)
15
SATA2 Connector (SATA2_2, Black)
16
SATA2 Connector (SATA2_3, Black)
17
SATA2 Connector (SATA2_4, Black)
18
SATA2 Connector (SATA2_5, Black)
19
64Mb SPI Flash
20
Intel P67 Chipset
21
Reset Switch (RSTBTN)
22
Power Switch (PWRBTN)
23
Power LED Header (PLED1)
24
System Panel Header (PANEL1, Black)
2
ASRock P67 Extreme4 Gen3 Motherboard
1
2
3
4
24.4cm (9.6 in)
ATX12V1
PWR_FAN1
Top:
RJ-45
USB 2.0
T: USB4
B: USB5
1394a
USB 3.0
CMOS
Battery
LAN
CHA_FAN2
CHA_FAN3
PHY
PCIE1
PCIE2
PCIE3
PCI1
P67 Extreme4 Gen3
PCIE4
RoHS
PCI2
ErP/EuP Ready
X
Fast USB
Front USB 3.0
PCIE5
1
HDMI_SPDIF1
PCI Express 3.0
COM1
USB8_9
USB10_11
IR1
FRONT_1394
1
1
1
1
1
FLOPPY1
34
33
32
31
30
29
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
5
6
7
8
9
10
1
CLRCMOS1
11
12
13
14
15
16
Intel
17
P67
18
64Mb
19
BIOS
20
21
RSTBTN
Dr.
22
PWRBTN
Debug
23
PLED1
1
USB3_2_3
PANEL1
USB12_13
PLED PWRBTN
SPEAKER1
1
1
1
HDLED RESET
28
27
26
25
24
Chassis Speaker Header
(SPEAKER 1, Black)
USB 3.0 Header (USB3_2_3, Black)
Dr. Debug
USB 2.0 Header (USB12_13, Black)
USB 2.0 Header (USB10_11, Black)
USB 2.0 Header (USB8_9, Black)
Front Panel IEEE 1394 Header
(FRONT_1394, Black)
Infrared Module Header (IR1)
Floppy Connector (FLOPPY1)
COM Port Header (COM1)
Front Panel Audio Header
(HD_AUDIO1, Black)
HDMI_SPDIF Header
(HDMI_SPDIF1, Black)
PCI Express 2.0 x16 Slot (PCIE5, Black)
PCI Slot (PCI2)
PCI Express 3.0 x16 Slot (PCIE4, Black)
PCI Slot (PCI1)
PCI Express 2.0 x1 Slot (PCIE3, Black)
PCI Express 3.0 x16 Slot (PCIE2, Black)
PCI Express 2.0 x1 Slot (PCIE1, Black)
SLI / XFIRE Power Connector
Chassis Fan Connector (CHA_FAN3)
Chassis Fan Connector (CHA_FAN2)
