Compak K-3 Elite Bedienungshandbuch Seite 21

NOTE: If a lot of coffee
comes out slowly, this is
because the coffee is set
LESS
MORE
to grind very fine. If a little
comes out very fast, it is
because the grind is very
thick. A perfect espresso
is achieved with a grinding
point of 25 ml of coffee
brewed in 25 seconds.
Fig. 5
Fig. 4
7.2. Regulating the coffee servings Model K-3 Elite
The dispensers are factory adjusted to serve an amount of approximately 7 gr of ground
coffee, but this quantity can be regulated between 6 and 10 gr, as follows: Remove the
ground coffee dispenser lid (8) and turn the dispensing regulation screw (9) clockwise to
obtain a smaller amount of coffee, and counter-clockwise to obtain a larger amount. Once
the quantity of each serving has been regulated, replace the ground coffee dispenser lid
(8). Fig. 5.
7.3. Coffee regulation for the Model K-3Touch
The K-3 Touch model grinding time is factory
regulated to serve portions of approximately 7 g. To
change the grinding time, turn off the machine using
the 3-position switch (10).
Turn the plastic axle located on the underside of the
machine. If turned clockwise, the quantity of coffee
will be increased and if turned counter-clockwise,
the amount will be reduced. Fig. 6.
Fig. 6
Turn the 3-position switch to position 1. Check that the amount of ground coffee is
correct. If not, repeat the operation.
8
Operation
8.1. Using the Model K-3 Elite
To turn the machine on and off, use the On-Off switch (14). The machine will start to grind
the coffee. If the automatic stop option is incorporated, the grinder will stop grinding when
the dispenser reaches the maximum level, and will restart after 8 portions of coffee have
been served, grinding again to the maximum level.
If the machine does not incorporate the automatic stop option, we recommend that you
fill the doser 75% of its capacity in order to guarantee consistent dosing.
