MIXER FEATURES
Note: The mixer controls do not have any MIDI function.
1.
MASTER VOLUME – Adjusts the output volume of the Program mix.
2.
CHANNEL GAIN – Adjusts the channel's pre-fader and pre-EQ gain level.
3.
CHANNEL TREBLE – Adjusts the high (treble) frequencies of the
corresponding channel.
4.
CHANNEL MID – Adjusts the mid-range frequencies of the corresponding
channel.
5.
CHANNEL BASS – Adjusts the low (bass) frequencies of the corresponding
channel.
6.
INPUT SELECTOR – Selects the input source to be routed to the
corresponding channel. Input jacks are located on the rear panel (plus the
USB port on the top panel).
7.
CUE – Press this button to send this channel's pre-fader signal to the Cue
Channel for monitoring. When engaged, the button will be lit.
8.
CHANNEL FADER – Adjusts the audio level on the corresponding channel.
9.
CROSSFADER – Blends audio playing between Channels 1 and 2. Sliding
this to the left plays Channel 1 and sliding to the right plays Channel 2.
Note: The crossfader is user-replaceable if it should ever wear out. Simply
remove the facepanel, then remove the screws holding it in position. Replace
the fader with a quality authorized replacement from your local Numark retailer
only.
10.
CUE SLIDER – Previews the audio playing on Channels 1 and 2. Sliding this
to the left plays Channel 1. Sliding to the right plays Channel 2.
11.
CUE GAIN – Adjusts the level of the headphone audio.
12.
LED METERS – Monitors the audio level of the Program mix.
DECK FEATURES
1.
EJECT – Press this button to eject the CD. If a CD is
currently playing, this button will have no effect.
2.
USB – Connect your favorite USB storage device to this
connector to allow the MIXDECK EXPRESS to read and
play back your music files. The MIXDECK EXPRESS only
supports the MP3 format so please make sure that your
audio files are encoded as MP3s if you would like to use
them with the MIXDECK EXPRESS.
Note: MIXDECK EXPRESS supports the HFS+, FAT and
NTFS files systems. HFS+ GUID Partition Table is not
supported at this time.
3.
SOURCE – Press the SOURCE button to choose which
audio source you want to play; CD, USB A, USB B, or you
can use the MIXDECK EXPRESS as a USB MIDI
controller. This button will not function if the MIXDECK
EXPRESS is currently playing.
4.
TRACK KNOB – Used to skip from track to track, for folder
navigation and as an "enter" button.
5.
BACK – When navigating a CD or device with folders, this
button will take you back to the previous level (folder).
6.
PLAY / PAUSE – Starts or resumes playback if the Deck is
paused. Pauses playback if the Deck is playing.
7.
CUE – Returns and pauses the music at the last set cue
point. The cue point is the last place in which the unit was
paused and then PLAY was pressed. Pressing and holding
a second time allows for temporary play of this point. You
can easily edit the cue point by turning the wheel. As you
rotate the wheel the music will sound. By stopping the
wheel and pressing PLAY a new point is set.
2
3
13
14
11
15
9
16
4
11
10
6
6
2
2
3
3
12
12
4
4
5
5
7
7
8
8
9
21
18 20
19
5
4
17
17 17
8
7
6
1
6
2
3
4
5
7
8
12
10
1
