Numark Mixdeck Express Bedienungsanleitung Seite 11

MAC
You will need to configure Traktor 2 so you can preview your audio.
Connect your MIXDECK EXPRESS.
1.
On each deck, press SOURCE to select "MIDI-PC" and press down on the TRACK KNOB.
2.
Open Traktor 2. In the window that appears, click the "Activate" button to register the software. The
3.
Native Instruments Service Center will launch. (You will need to be connected to the internet to access
the Service Center to register your software.)
In the Service Center login window, click "Create new User Account" (if you do not already have one)
4.
and follow the on-screen instructions to complete your registration. (You will need the serial number on
the included DVD sleeve to do this.)
After registering your software and opening it, click the "cog" icon or go to Traktor
5.
Traktor 2 Preferences window will appear.
Under the Audio Setup tab, for Device, select "MixDeck Express."
6.
Select the Output Routing tab. For "Output Monitor," select Channels 3 and 4. For "Output Master,"
7.
select Channels 1 and 2. (Make sure the Mixing Mode is set to "Internal.")
Close the Preferences windows. You are now ready to perform.
8.
Note: If you are experiencing too much latency (lag from the time you strum the strings to the time you hear
the sound in your computer), you can decrease the buffer to 256 or 128 samples. If you are experiencing
"clipping," pops, or glitches in playback, you may want to raise the buffer size to 512 or above. To change the
buffer size, open Traktor 2's Preferences window and click the Audio Setup tab. Adjust the "Audio Latency"
slider by clicking on it. The latency (in ms) is shown next to the slider.
Note: For additional assistance and information, you can find Traktor 2's manual by going to the software's
"Help" menu, "Open Manual," then selecting the manual you want.
TRAKTOR 2 MAP
If you already own Native Instruments Traktor 2, refer
to this control map to see what software features can
be controlled by MIXDECK EXPRESS. (Note: The
mixer controls do not have any MIDI function.)
1. Unload/Clear Deck
2. Play/Pause
3. Cue
4. Scratch Mode
5. Search Mode
6. Reverse
7. Brake
8. Jog Wheel
9. Pitch Fader
10. Pitch Bend
11. Pitch Range
12. Tap (BPM)
13. Deck Select
14. (Loop) Mode
15. Time Display
16. Browser Back
17. Loop In
18. Loop Out
19. Reloop
20. Track Select (Push to enter)
12
11
6
9
4
10
11
Preferences. The
13 14 15 16
20
17 18 19
8
3 2
7
5
1
