RF Rx SW868/SW915/SW917/SW922-2W-RS232
//
Montage- und Anschlussanleitung / Funkempfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur sans fil
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor de rádio frequência
Инструкция по монтажу и подключению / Радиоприемник сигнала
English
Operation LED 1 LED MD
mode
Latching func- on flashes
tion (addition- slowly
ally selectable)
Teaching in of switches
- Press push-button S1 approx. 1 s
- LED MD flashes slowly (2 Hz)
- Press push-button S2 for channel seletion
- Actuate switch/command device to be taught in
- The LED of the corresponding channel is off for short time
- To leave teach-in mode press push-button S1 for approx. 1 s
- LED MD is on
Deleting one switch
- Press push-button S1 for 5 s until LED MD flashes fast
- Press push-button S2 for channel seletion
- Actuate switch/command device to be deleted
- The LED of the corresponding channel is off for short time
- Press push-button S1 for approx. 1 s to leave delete mode
- LED MD lights green
Inverse teaching in of one switch
- Procedure like teach-in but switch must be actuated before proce-
dure is started by pressing S1
Deleting all switches
- Press push-button S1 for 5 s
- LED MD flashes fast (5 Hz)
- LED channel selection is on
- Release push-button S1
- Repress push-button S1 for 5 s until LED MD is off
- LED MD is on and LED 1 is off
- Operation mode was set back to standard
- Release push-button S1
- LED MD is on and LED 1 flashes fast
RF Rx SW868/915/922-2W-RS232
Selection of the baudrate
- Standard preset baudrate is 9 600 Bd
- Press push-button S1 and S2
- LEDs 1, 2 and MD are flashing
- Press push-button S1 for selection of baudrate
- LEDs B1 and B2 indicate the baudrate
- Press push-button S1 to select the desired baudrate
Function
Latching function/impulse
function
4 / 20
LED B1 LED B2
off off
on off
off on
on on
- Press push-button S1 to show the selected baudrate.
- Press push-button S1 and S2 to quit without changing the setting.
Telegrams
All steute Wireless telegrams are displayed at the serial interface.

Maintenance

With rough conditions, we recommend routine maintenance as follows:
1. Remove all dirt or particles.
Cleaning
- In case of damp cleaning: use water or mild, non-scratching, non-
chafing cleaners.
- Do not use aggressive cleaners or solvents.
Clean enclosure on the outside only. Clean enclosure with household
cleaning agents. Do not use compressed air to clean.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately.
Baudrate
9 600 Bd
19 200 Bd
38 400 Bd
57 600 Bd
