BenQ LU9915 Installationsanleitung Seite 10

Ultra Short Reflection
Screen
H1
H2
L1: Screen to the point of mirror
L2: Screen to projector front
L3: Screen to project back
H1: Screen bottom to projector top side
H2: Screen bottom to projector bottom
Screen size
Diagonal Width
inch mm inch
100 2540 85
120 3048 102
150 3810 128
200 5080 170
250 6350 213
300 7620 256
350 8890 299
Note:
• For more visualized instructions, please go to BenQ calculator website http://projectorcalculator.benq.com/.
• Precise installation is prefered to be done by professionals. Contact your dealer for more information.
• When UST lens is installed to the projector, it is recommended to loosen the screw on the support kit and make
the arm movable before adjustment.
• The User Manual for UST Lens installation is available from local BenQ website.
10
285
873
L1
L2
Height H1
mm inch mm inch
2166 53 1355 19
2599 64 1627 23
3247 80 2032 30
4330 107 2711 41
5415 133 3391 52
6500 160 4071 63
7585 187 4752 74
5J.JCY37.001
Ultra Short Reflection
H2 L1
mm inch mm inch
485 28 701 33
596 32 812 39
763 39 979 48
1041 49 1257 63
1320 60 1536 78
1598 71 1814 93
1877 82 2093 108
L2 L3
mm inch mm inch
849 22 564 -1
1000 28 715 5
1227 37 942 14
1606 52 1321 29
1984 67 1699 44
2362 82 2077 59
2741 97 2456 74
mm
-24
127
354
733
1111
1489
1868
