Installation Work

Installation Place
- When installing in the control panel, check to ensure that the installation surface is vertical and sufficiently
strong. If not, the BACnet
®
- Install the BACnet adaptor with a sufficient space around the BACnet
maintenance as shown in the figure below "Service Space".
®
- Install the BACnet adaptor with at least 3 meters away from the electromagnetic wave radiator to prevent
the effect of the aerial propagation of noise.
- DO NOT install the BACnet
Service Space
50
®
Fix the BACnet adaptor with M5 screws as shown below.
Accessory: Installation Manual
Hitachi Appliances, Inc.
HITACHI
Launching of HC-A64BNP BACnet
®
adaptor may fall, resulting in a serious accident.
®
adaptor where it will be exposed to direct sunlight.
(240)
50
(240)
4-M5
220
