Problem Possible cause
The beam interruption
time is shorter than the
set response time.
Alarm LED Beam alignment is out.
continues
Shading object between
to light.
the transmitter and the
receiver.
Unit optics are dirty.
Frequency channel is not
compatible between the
transmitter and the
receiver.
Intermittent Bad wiring connection.
alarms
Change of supply
voltage.
Shading object between
transmitter and the
receiver.
A large electrical noise
source, such as a power
machine, is located near
the transmitter and the
receiver.
Unstable installation of
transmitter and receiver.
Dirty transmitter or
receiver optics.
Incorrect alignment.
Small animals may be
passing through the two
beams.
Beam power switch is set
to L, which does not keep
enough sensitivity
allowance.

Specifications

Model PB601
Detection Near infrared beam interruption system. (TX-RX 4
system beams simultaneous interuption)
Infrared beam LED pulsed beam, double modulation
Outdoor 50 m
Protection
distance
Max. arrival Tenfold (500 m)
distance
50-700 msec. variable (Standard = 50 msec.)
Response
time
Power supply 12-30 VDC (non polarity)
60 mA at
Current
consumption protection (max.
95 mA)
Alarm output Dry contact relay output N.C./N.O.
Contact action: interruption time + delay time (1-3 s)
Contact capacity: 30 V AC/DC, 1 A or less
10 / 44
Remedy
Adjust the beam response
time.
Check and adjust again.
Remove the shading
objects.
Clean the optics with a soft
cloth.
Readjust to the same
channel.
Check again.
Stabilize supply voltage.
Remove the shading object.
Change location of the
installation.
Stabilize.
Clean the optics with a soft
cloth.
Check and adjust again.
Increase the response time.
(impossible in a location
where the intruder can run
at full speed.)
Set the beam power switch
at H and make the unit gain
locked with the receiver
cover detached.
PB611 PB621
Outdoor 100 m Outdoor 200 m
Tenfold (1000 Tenfold (2000 m)
m)
75 mA at 80 mA at
protection (max. protection (max.
105 mA) 120 mA)
Model PB601
Tamper Dry contact relay 1b (N/C)
output
Action: activated when cover is detached
Contact capacity: 30 V AC/DC, 0.1 mA or less
Alarm LED Red LED (receiver). ON: when an alarm is initiated
Attenuation Red LED (receiver). ON: when a beam is attenuated
LED
Functions Modulated beam frequency selection. Tone indicator.
Environmental module. Beam power selection. Alarm
memory indication. Programmed AGC. Auto-gain
function. Monitor jack.
Horizontal: 90° Vertical: 10°
Beam
adjustment
−35°C to +66°C
Ambient
temperature
change
Mounting Outdoor
positions
Wiring Terminals
Weight Transmitter: 1200 g. Receiver: 1300 g
Appearance PC resin (wine red)

Regulatory information

Manufacturer PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092,
USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings THESE PRODUCTS ARE INTENDED FOR
and disclaimers SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
Environmental Class 4
class
European Union UTC Fire & Security hereby declares that this
directives device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info
PB611 PB621
or scan the QR code.
P/N 1077839 • REV C • ISS 19MAR19
