Fujitsu Siemens Computers D1567 Handbuch Seite 23

Audio S/PDIF
Pin
1
2
3
CD-ROM audio
Pin
1
2
3
4
AUX-Audio In
Pin
1
2
3
4
A26361-D1567-Z121-1-6319
Pinbelegung interne Anschlüsse
Signal
VCC
SPDIF out
GND
Signal
Left CD audio input
CD GND
CD GND
Right CD audio input
Signal
Left AUX audio input
Analog GND
Analog GND
Right AUX audio input
1
1
1
Deutsch - 13
