2.7 Smart Switches

The motherboard has ten smart switches: Power Switch, Reset Switch, Clear CMOS
Switch, Rapid OC Buttons, Menu Button, PCIe ON/OFF Switch, Slow Mode Switch,
BIOS Selection Switch and LN2 Mode Switch.
Power Switch
(PWR)
(see p.1, No. 24)
Reset Switch
(RST)
(see p.1 No. 25)
Clear CMOS Switch
(CLRCBTN1)
(see p.4, No. 4)
This function is workable only when you power off your computer and unplug the power
supply.
+ / - Rapid OC But-
tons
(MINUS: see p.1, No.
27)
(PLUS: see p.1, No.
28)
This overclocking behavior depends on the system configuration, such as memory capabil-
ity, thermal solution, etc. Overclocking may affect your system stability, or even cause dam-
age to the components and devices. We are not responsible for possible damage caused by
overclocking.
Menu Button
(MENU: see p.7, No.
30)
28
Power Switch allows users to
Power
quickly turn on/off the system.
Reset Switch allows users to
quickly reset the system.
Reset
Clear CMOS Switch allows
users to quickly clear the
CMOS values.
+ / - Rapid OC Buttons allow
+
users to quickly and easily
adjust OC frequency in Rapid
OC.
-
Use MENU Button in Rapid
MENU
OC to quickly toggle among
various overclocking options,
such as BCLK, Ratio and
Cache Ratio.
