Connector
BIOS
Feature
10
• 1 x COM Port Header
• 1 x TPM Header
• 1 x Power LED header
• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
• 4 x Chassis Fan Connectors (1 x 4-pin, 3 x 3-pin)
• 1 x Power Fan Connector (3-pin)
• 1 x 24 pin ATX Power Connector
• 2 x 8 pin 12V Power Connectors (Hi-Density Power
Connector)
• 1 x HDD Saver Connector
• 1 x PCIe Power Connector
• 1 x Front Panel Audio Connector
• 1 x Thunderbolt AIC Connector
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
• 1 x Power Switch with LED
• 1 x Reset Switch with LED
• V-Probe
TM
: 2 x 7-set of onboard voltage measurement points
laid
• Rapid OC Buttons: +/- buttons to adjust OC frequency
• 1 x Menu Button
• 1 x PCIe ON/OFF Switch
• 1 x Post Status Checker (PSC)
• 1 x Slow Mode Switch
• 1 x LN2 Mode Switch
• 1 x BIOS Selection Switch
• 2 x 64Mb AMI UEFI Legal BIOS with multilingual GUI sup-
port (1 x Main BIOS and 1 x Backup BIOS)
• Supports Secure Backup UEFI Technology
• ACPI 1.1 Compliant wake up events
• SMBIOS 2.3.1 Support
• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
