RULES FOR SAFE DRIVING
For the safety of the child, before starting up the
vehicle read and carefully follow the following
instructions.
• Teach the child how to use the vehicle properly for
safe and enjoyable driving.
• Before starting, check that there are no people or
objects obstructing the vehicle's path.
• Drive with hands on the handlebars/steering wheel
and always watch the road ahead.
• Brake in good time to avoid collisions.
2nd GEAR (if present)
Initially, use in 1st gear is recommended. Before
enabling 2nd gear, check that the child has learned to
use the handlebars/steering wheel, 1st gear and the
brake correctly, and has become familiar with the
vehicle.
WARNING!
• Check that all the wheel fixing studs/nuts are
fastened properly.
• If the vehicle is overloaded, as can happen on soft
sand, mud, or very uneven ground, the overload
switch will immediately disconnect the power. The
power supply will be restored after a few seconds.
• If the vehicle is overloaded on steep slopes, the
overload cut-out will immediately disconnect the
power. If this happens,
REMOVE THE FOOT FROM THE
. The electrical brake will be
ACCELERATOR
activated, slowing down the descent of the vehicle.
• Only for 12 and 24 Volt vehicles: in first gear the
vehicle has a differential effect like a real motor
vehicle; on smooth terrain and with just one child
on board, the two wheels can turn at different
speeds and they can slip and slow down.
UNINTERRUPTED FUN: Keep a spare set of charged
batteries ready for use.
PROBLEMS?
THE VEHICLE DOES NOT WORK?
• Check that there are no disconnected cables under
the accelerator plate.
• Check the operation of the accelerator button and
replace it if necessary.
• Check that the battery is connected to the
electrical system.
THE VEHICLE LACKS POWER?
• Charge the batteries. If after charging the problem
persists, have the battery and charger checked by
an assistance centre.

ASSISTANCE SERVICE

offers an after-sales assistance service,
PEG PEREGO
directly or through a network of authorized
assistance centres, for any repairs or replacements
and the sale of original spare parts. To contact the
assistance centres refer to the "Assistance Centres"
booklet included in the packaging.
The item's serial number must always be quoted. See
the page on spare parts to find out how to identify the
serial number.
Peg Perego always strive to best satisfy their
customers' needs. Knowing the opinions of our
customers is therefore very important and valuable
to us. We would be very grateful if, once you have
used the product, you would fill out the
which you can find on
SATISFACTION QUESTIONNAIRE
the internet at: www.pegperego.com, making
any observations or suggestions you might have.
ASSEMBLY INSTRUCTIONS
WARNING
ASSEMBLY MUST ONLY BE CARRIED OUT BY
ADULTS. TAKE CARE WHEN REMOVING THE
VEHICLE FROM ITS PACKAGING. ALL THE
SCREWS AND SMALL PARTS ARE CONTAINED IN
A BAG INSIDE THE PACKAGING. THE BATTERY
MAY ALREADY BE FITTED INSIDE THE ITEM.
1-2 • Unscrew and remove the bottom of the trailer
from the bottom of the tractor.
3 • Insert one of the 4 self-locking washers (the
tractor comes with 2 spare washers) into the
special tool provided with the tractor.
ATTENTION: the tabs on the self-locking washer
must be turned towards the interior of the tool
(see detail A).
4 • Remove the axle from the packing. Remove the
protective caps from the axle. Insert the axle by
pounding the special tool all the way in using a
hammer. Remove the tool.
5 • Slip the following components onto the axle in
this order: washer, wheel, second wheel, washer
(four washers come with the tractor; two of
them are spares). ATTENTION: Check to make
sure that the wheels have been inserted
correctly on the axle. The hubcaps must be
turned outwards.
6 • Place a self-locking washer in the special tool,
and insert the prepared axle, pounding it all the
way in.
7 • Attach the wheel unit to the base of the trailer
by pressing on it.
8 • Insert the red pin into the end of the trailer.
9 • Remove the 5 protective caps from the bottom
of the bed.
10 • Attach the bottom of the trailer (prepared
beforehand) to the bed by pressing, as shown in
the figure.
11 • Assemble the 3 sides of the trailer, ensuring that
the parts with the wooden effect are facing
outwards.
12 • Fit the assembled parts into the slots in the base
of the trailer.
13 • Attach the 2 hubcaps to the wheels on the
trailer (Attention, in the packaging you will find 6
hubcaps; the remaining 4 are to be attached to
the wheels of the tractor).
14 • Attach the plastic drop to the hood, as shown in
the figure.
15 • Apply the stickers to the special areas on the
front headlights.
16 • Position the headlight glass by attaching the
outer side.
17 • Press as shown in the figure to snap the glass
into place.
18 • Repeat this step for the other front headlight.
19 • Position one of the two parts of the weight on
the front of the tractor.
20 • Join the other part of the weight by pressing the
two parts together.
21 • Insert the pin into the special opening in the
weight.
22 • Push the pin all the way in.
23 • Press the side inserts into place on the body.
24 • Press the ring nut into place under the steering
wheel and the cap.
25 • Push the steering column through the bottom of
the tractor to the upper part of the body.
26 • Hold the column in place and slip the steering
wheel onto it.
27 • Fasten the steering wheel with its screw and nut,
being careful to insert the screw into the circular
hole and to screw the nut onto the hexagonal
part.
28 • Apply the stickers to the special areas on the
rear headlights as shown in the figure.
29 • Attach the headlights by pressing from the
bottom upwards.
30 • Remove the seat support.
31 • Unscrew the knobs on the bottom of the seat.
32 • Line the seat up with the two holes on the seat
support.
33 • The seat can be adjusted to 2 positions to suit
the height of the child (see figure).
34 • After adjusting the seat, tighten the 2 knobs that
hold it in place.
35 • Reposition the seat support on the body of the
tractor and tighten the 2 screws.
36 • Position the roll bar (see figure).
37 • Push the roll bar all the way in.
38 • Tighten the 2 lock screws.
CONSUMER
39 • Press the gas tank cap into place on the back of
the tractor.
40 • Attach the trailer to the tractor as follows: insert
the trailer coupling into the opening on the back
ASSEMBLY
of the tractor, and rotate it (see fig. 41).
41 • Position 1: the trailer can be removed.
Position 2: the trailer is locked into place.
WARNING: The trailer will hold a load weighing
up to 10 kg.
42 • Loosen the two safety screws from the sides of
the cab, and remove the two plastic disks (save
the disks for putting the cab back on).
43 • Press the two buttons and at the same time
widen the cab to detach it, as shown in the
figure.
44 • Lift the cab off.
45 • Connect the battery plug to the electrical
system.
46 • Reposition the cab by inserting the front hook
into the opening on the bottom of the tractor
(see detail).
47 • Slightly widen the cab, and lower it to its original
position. Replace the two plastic disks and fasten
everything down with the screws.
VEHICLE FEATURES AND
INSTRUCTIONS FOR USE
48 • GEAR SHIFT LEVER. The vehicle has 3 speeds.
ATTENTION: when the vehicle is taken out of
the packing, it runs only in first gear and reverse
gear. To use the second speed, follow the
instructions in figure 49.
49 • Loosen the lock screw for the second speed (fig.
A). Turn the lock screw to the next notch (fig. B),
and tighten it. All of the gears are now ready for
use.
50 • ACCELERATOR PEDAL/ELECTRIC BRAKE.
When the foot is lifted from the accelerator
pedal, the electric brake automatically stops the
tractor.
REPLACING THE BATTERY
PLEASE NOTE: THE PICTURES OF THE BATTERIES
ARE FOR ILLUSTRATIVE PURPOSES ONLY. YOUR
BATTERY MAY BE DIFFERENT FROM THE MODEL
SHOWN. THIS DOES NOT AFFECT THE
REPLACEMENT AND CHARGING PROCEDURES
DESCRIBED.
51 • Unscrew the two safety screws from the cab.
Remove the cab. Disconnect the battery from
the electrical system and loosen the 2 screws on
the battery brace, as shown in the figure.
52 • Extract the battery.
53 • Remove the battery clamp from the dead battery
and put it on the new battery.
54 • If you have bought or own a Peg Perego
12V/12Ah battery, you will have to remove the
plastic filler (A) by slipping it off the battery
clamp.
55 • Reposition the new battery with the battery
clamp in its housing. Fasten the clamp with the
two screws. Connect the battery plugs to the
electrical system. Reposition the cab. Attention:
always screw the two safety screws back onto
the sides of the cab.
BATTERY RECHARGE
WARNING: BATTERY CHARGING AND EVERY
OTHER OPERATION ON THE ELECTRICAL SYSTEM
MUST BE CARRIED OUT BY ADULTS ONLY.
THE BATTERY CAN ALSO BE CHARGED WITHOUT
REMOVING IT FROM THE TOY.
56 • Open the hood, as described above. Disconnect
the battery from the electrical system by
pressing on the side of the plug.
57 • Insert the battery charger plug into an electrical
outlet, following the instructions that come with
the charger. Connect point B to point C on the
battery charger.
58 • When the battery has been completely
recharged, disconnect the battery charger from
the electrical outlet, and disconnect point C from
point B.
59 • Insert point B into point A, pressing until it clicks
into place. Replace the battery brace. Always
remember to close and fasten the cover on the
battery compartment when you have finished
working on the battery.
