AXIS Q1615 Mk II Network Camera
Adjust zoom and focus for optional lenses
If the camera is mounted so that you cannot look at the image and access the lens at the same
time, use the Focus Assistant, see Focus assistant for optional lenses on page 20.
Note
Only valid for optional P-iris, DC-iris or manual iris lenses.
1. Go to Settings > Image > Focus.
2. Click Fine-tune.
3. Adjust the autofocus area to cover the part of the image that you want to be in focus.
If you don't select an autofocus area, the camera focuses on the entire scene. We
recommend that you focus on a static object.
4. Click Reset focus.
5. Loosen the zoom and focus pullers on the lens by turning them counter-clockwise.
6. Move the zoom and focus ring to set zoom and focus and check the image quality in
the image window.
7. Re-tighten the zoom and focus pullers when satisfied with the image focus.
8. If the image focus has slightly changed while tightening the zoom and focus pullers,
click Fine-tune.
9. If you want to slightly adjust the focus position, move the Focus position slider.
Focus assistant for optional lenses
Note
• Only valid for optional P-iris, DC-iris or manual iris lenses.
• The view in front of the camera should not be changed during focus adjustment (steps
5 and 6). If the camera is moved, or if a finger or other object is placed in front of the
lens, steps 3–7 will have to be repeated.
• If movements in front of the camera cannot be avoided, the Focus Assistant should not
be used.
• If the camera is mounted so that the function button cannot be accessed, you can still
use the Focus Assistant. Follow the instructions below but mount the camera after step
4, pressing the function button instead and skip step 7.
To focus your network camera using the Focus Assistant, follow steps 1–4 under Adjust zoom and
focus for optional lenses on page 20 before you start with the steps below.
1. Mount or place the camera so that it cannot be moved.
2. Loosen the zoom puller by turning it counter-clockwise. Move the puller to set the
zoom level. Re-tighten the zoom puller.
3. Set the camera to its extreme distant-focus position by loosening the lock screw for the
focus ring and turning the focus ring fully counter-clockwise.
