AXIS Q1615 Mk II Network Camera
Status LED behavior for focus assistant
Note
Only valid for optional P-iris, DC-iris or manual iris lenses.
The status LED flashes when the Focus Assistant is active.
Color Indication
Red The image is out of focus.
Adjust the lens.
Amber The image is close to focus.
The lens needs fine tuning.
Green The image is in focus.
Buzzer signal for focus assistant
Note
Only valid for optional P-iris, DC-iris or manual iris lenses.
Buzzer
Fast interval
Medium interval
Slow interval
Status LED behavior and buzzer signal for leveling assistant
For information on the function button used for leveling the camera, see .
Press and hold the function button (2) for more than two seconds to level the camera.
• When the camera is level, both LEDs are steady green, and the beep is continuous.
• When the camera is not level, the LEDs flash a combination of red, green and orange, and
the beep occurs at slow intervals.
Both LEDs briefly flash green to indicate that the leveling is getting better.
Connectors and buttons
For specifications and operating conditions, see page 16.
Network connector
RJ45 Ethernet connector with Power over Ethernet (PoE).
Lens
Optimally adjusted
Less optimally adjusted
Poorly adjusted
