4.2 Normal operation
Avoid dry running ( >1 min).
With the fuel nozzle closed and the pump filled with medium it may
be operated for max. 1 min, since otherwise this can lead to excessive heating and pump
vane damage. After the filling process the fuel nozzle must be hung in the fuel nozzle
holder. A defective hose can cause fouling. The fuel hose should not remain lying on the
ground in order to prevent damage to it (e.g. by driving over it).
1. Make voltage connection via mains plug.
2. Hold the fuel nozzle in filling container or in vehicle tank and press up the
fuel lever according to the desired fill quantity or lock with fixing clip.
The automatic fuel nozzle automatically switches off if the tank is full. If the filling
process is to be finished before this, release the fuel lever or pull the lever up
briefly if it is latched and then release it.
3. Hang the fuel nozzle in the holder. The motor switches off.
- See also Operating Instructions for automatic nozzle and
Operating Instructions for Meter Z98.

5. Maintenance

- The dispensing pump VISION basically does not need any maintenance.
- Due to existing regulations, however, pump housing, discharge hose and nozzle
must regularly be checked for damage.
- The discharge hose can easily be replaced releasing the threads.
6. Repair/Service
- The dispensing pump VISION has been designed with the purpose of being
able to operate with least possible maintenance. This is obtained by using the
dispensing pump according to this operating manual. Should you, however, after
all need service, we kindly ask you to contact the Tuthill Customer Service.
