Chapter 1. Foreword

1.1. Preface

This manual has been drawn up in compliance with the UNI10893 standard dated July 2000. It is meant for all users in
order to enable them to use the machine correctly. Keep it in a place which can be easily accessed in the proximity of the
machine and which is known to all users. This manual is an integral part of the machine for safety reasons. We wish to
specify the symbols in use here below in order to improve their understanding.
ATTENTION:
Accident prevention rules for the operator. This warning indicates the presence of dangers which
can injure the person operating on the machine.
ATTENTION:
Hot members. It shows the danger of burning, thus involving the risk of a serious accident for the
exposed person.
WARNING:
It indicates the possibility of damaging the machine and/or its components.
All reproduction rights of this manual are reserved to the manufacturer. Partial or complete reproduction is forbidden as
provided by the law. Descriptions and pictures provided in this manual are not binding. Therefore the manufacturer,
reserves the right to make any change considered necessary. This manual cannot be transferred for viewing to third
parties without authorisation in writing from the manufacturing company. The machine must be used only for the purpose
it was built for. Any other use shall be considered "improper" and therefore dangerous. Before carrying out any operation
on the machine it is compulsory to read carefully all instructions provided in this manual, in order to avoid possible
damage to the machine, to people and property.
Do not operate if in doubt about the correct interpretation of the instructions.
Contact the manufacturer in order to obtain the necessary explanation.
This machine is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack experience and knowledge, unless they have been given supervision or instruction concerning use of
the machine by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the machine.
Upon delivery check that the machine is complete in all parts.
Possible faults shall be immediately reported to the manufacturer.
The manufacturing company declines any liability in case of machine improper use and/or in case of damage resulting
from operations carried out on the machine that are not mentioned in this manual.

1.2. Performances of packaging machine

You have bought a machine with outstanding features and performance and we thank You very much for Your confidence in choosing it.
The system is the only one of its kind and has achieved worldwide success with more than 150000 units operating in the field of
packaging and wrapping. The technological concept underling its design, as well as the components and materials used in the
manufacturing and testing process are the best assurance of proper operation and long-lasting liability.
Is a sealing machine for plastic films, whether heat-shrinking or not, compact in size and featuring high-performance service.
One-fold films can be used, ranging from 15 to 50 microns in thickness, suitable for both technical and food-related applications.

1.3. Machine technical data

Electrical system
Voltage (V): see data on plate
Frequency (Hz): see data on plate
Maximum absorbed power (W): see data on plate
Maximum absorbed current (A): see data on plate
N.B.: when contacting the Manufacturer, always indicate the model and the serial number
specified on the plate on the rear part of the machine.
Width "a"
Length "b"
Height "c"
Weight
Width "a"
Length "b"
Height "c"
Weight
Maximum production
10
Modular 50 Modular 70
1590 mm 2180 mm
960 mm 1040 mm
1370 mm 1430 mm
200Kg 290 Kg
Modular 50 Modular 70
1480 mm 2070 mm
850 mm 960 mm
1400 mm 1510 mm
170 Kg 243 Kg
900 packs/hour 900 packs/hour
