VTrak Quick Start Guide
Figure 8 SAN data and management connections, single controller
Mac
A two-path connection, as shown above, is the minimum requirement for VTrak.
Management
cables
FC data cables
Fiber Channel Switch
Mgmt
UPS
FC 1 FC 2
4 4
2 2
1 1
Gb/s Gb/s 115200
8 N 1
12
Ethernet Switch
VTrak
