Operation
Display
The values will be shown with three digits, and with a setting
you can determine whether the temperature are to be shown
in °C or in °F.
Light-emitting diodes (LED) on front panel
There are LED's on the front panel which will light up when
the belonging relay is activated.
The three lowermost LED's will flash, if there is an error in the
regulation.
In this situation you can upload the error code on the display
and cancel the alarm by giving the uppermost button a brief
push.
