HP Designjet 3D Printer Einführende Informationen Seite 5

1
2
3
4
5
6
7
1 Model Material Y Connector
2 Model Material Tube
3 AC Power Cord Connector
4 Circuit Breaker
5 Material Bay
6 Optional Model Material Tube
7 Optional Material Bay
8 Support Material Y Connector
Rear view of printer
9 Support Material Tube
10 UPS Connection
1 1 Material Bay Cable Connector
12 RJ-45 Network Connector
13 Diagnostics Cable Connector
14 Material Bay Communications Cable
15 Optional Material Bay Communications Cable
16 Optional Support Material Tube
