AMV 335, AMV 435
❷
①
②
④ - for 24V
④ - for 230V
7.5 sec/mm (FAST) 15 sec/mm (SLOW)
S [mm] T [sec]
10 75
15 112.5
20 150
VI.LE.I4.3B
③
-A
S [mm] T [sec]
10 150
15 225
20 300
❸
❹
red (green if used with AB-QM)
green (red if used with AB-QM)
⑤
red (green if used with AB-QM)
green (red if used with AB-QM)
